User Assignments 8-11
MA4000 Installation Manager User Guide - Revision 6
• Service Restrictions (SFC) field
You can select either Use Myline Settings, SF
C - 0
Reserved for Trunks, SFC - 1 through SFC - 13, SFC -14
Conferencing, or SFC - 15 ACD.
• Call Forwarding field
You can select either the Defa
ult Call Forwarding, None,
Use Myline Settings, or New option.
•Name Display fiel
d
Select the None, Use Myline Settings or Cus
tom option.
If the Custom option is selected in the Name Display field, the Custom Name
Display Value field displays.
Figure 8-12
Button Template Editor - Feature Type: Station - Name Display: Custom
NOTE
